Expansion module FLC18E-4AI-I

Expansion module FLC18E-4AI-I

FLC18E-4AI-I, 5908312599432

Product description

Programmable controller. Expansion module of analog inputs.
FLC is a universal, programmable logic controller, which can control the elements of domestic and industrial electrical installation (for example lighting control, roller blind control, watering the garden, control of simple machines).

4 analog inputs 0/4 ÷ 20 mA.
With the built-in user panel it does not require combining with costly external panels, while at the same time providing a user with a preview and configuration of the control system parameters. The controller is equipped with advanced communication interfaces and allows for easy connection to professional visualization stations (using the Modbus protocol).


Software tools
Free software tool FLCLogic Soft is used for programming the FLOGIC controllers. The application allows you to write a program, test it with the simulator (without connection with the controller), load it to the controller and perform hardware tests (preview of the operation of the actual device with the possibility of recording digital and analog data).

Typeexpansion module
Power supply voltage12÷24 V DC
Number of analog inputs4 (AI1÷AI4)
Analog inputs - measuring range0/4÷20 mA
Analog inputs - resolution10 bit
Analog inputs - processing time50 ms
Weight400 g
Resistance to instantaneous power failure5 ms
Cooperation with CPU modulesFLC18-12DI-6R
Terminalpluggable terminal blocks 1,5 mm²
Tightening torque0,4 Nm
Power consumption1 W
Working temperature-20÷55°C
Assemblyon rail 35 mm
Ingress Protection MarkingIP20
