Signal lamp LK-712B 30÷130 V AC/DC

Signal lamp LK-712B 30÷130 V AC/DC View larger
Previous Next

Signal lamp LK-712B 30÷130 V AC/DC

LK-712B-30-130V, 5908312591306

Product description

A single LED. Color blue. Voltage range 30÷130 V AC/DC.
Designed to optically signal the presence of voltage in a electrical circuit.

Functioning
The presence of voltage in the circuit is indicated luminous LED.


Implementation

TypeLED Colours
LK-712 G          1× green
LK-712 Y          1× yellow
LK-712 R          1× red
LK-712 B          1× blue

Order labelling method

LK-712   B  30÷130V  ——  supply
             â”‚
          colour

Power supply voltage30÷130 V AC/DC
Power control1 × LED (8×4 mm)
LED colors1 x blue
Terminalpluggable terminal blocks 2,5 mm²
Tightening torque0,4 Nm
Power consumption0,8 W
Working temperature-25 ÷ 50 °C
Dimensions1 module (18 mm)
Assemblyon rail 35 mm
Ingress Protection MarkingIP20

LK-712G 5÷10 V AC/DC manual (51.07k)

LK-712B 30-130V outline CAD dxf (387.07k)

LK WN declaration CE 2023 (179.86k)

LK-712B 30-130V Bedienungsanleitung (645.09k)
