Separator of input signal SEP-01

Separator of input signal SEP-01

SEP-01

Separator of input signal.
The SEP-01 serve to separating of input signal in automatic arrangement with separated control groups and central control.

Functioning

SEP-01
Control signal is passed to 4→7; 6 →9. In the opposite direction the signal is blocked.

SEP-02
Control signal is passed to 1→2; 3 →4. In the opposite direction the signal is blocked.

Example of use
Group control system made bistable relays BIS-412.
[Goâ–ş]

System group control blinds. [Goâ–ş]


Maximum load current1 A 250 V
terminalscrew terminals 2,5 mm²
Tightening torque0,4 Nm
Working temperature-25÷40°C
dimensions1 module (18 mm)
Assemblyon rail 35 mm
Level of securityIP20
