GATE - wifi gate controller

Reference: Wi-TO2S2, EAN13: 5902431674162

Product description

2-channel gate controller designed for integration with any automation of gate and garage gate drives.

GATE - is a two-channel controller for gates or gates and wickets. It allows to define the device statuses: "gate closed", "gate open". Due to the architecture of the wifi system, the gate can be controlled via the cloud or only locally via wifi or bluetooth. To improve the signal strength, the GATE module is equipped with an external antenna. Hermetic casing guarantees uninterrupted operation of the controller outside. The GATE supports all types of gates, except for roller gates.

Application for phones and tablets

Remote access via Wi-Fi and F&F cloud

Remote control of gate and wicket drives

Properties

Designed for integration with any gate drive system;
Ability to control gate, two gates or a gate and a wicket;
Support for two local inputs enabling:

opening/closing a gate or wicket;
connection of gate or wicket opening/closing sensors;

REST API support enabling integration of the controller also with other home automation systems;
External antenna for extended operating range;
Hermetic housing suitable for outdoor installation.

FOX - Wi-Fi control system

Easy to install and rich in possibilities, wireless home automation system.

To control devices, the FOX system uses a free mobile application, which is available for devices with iOS and Android systems.
The application allows you to manage the installed modules in a simple and intuitive way. Thanks to the use of the home Wi-Fi network and the F&F cloud, you have the ability to constantly control devices at home from anywhere in the world with Internet access.
If you do not want to control your Fox system from outside your home, you can choose not to use the F&F cloud and still fully enjoy the functional control that works only over your local Wi-Fi or Bluetooth network.

FOX - system sterowania Wi-Fi - aplikacja mobilna

Application for Android devices

Application for iOS devices

Power supply voltage	9÷30 V DC; 16÷27 V AC
Ilość wejść sterujących	2
Control input	9÷30 V DC
Maximum AC-1 load current	mniej niż 20 mA
Napięcie	40 V
Control pulse current	mniej niż 3 mA
Radio frequency	2,4 GHz
Transmission	WI-FI
Radio power (IEEE 802.11n)	≤ 13 dBm
Receiver sensitivity	-98 dBm
The length of the antenna wire	1 m/25 mm
Terminal	zaciski sprężynowe 0,14÷0,5 mm²
Power consumption	czuwanie: 1,2 W: praca (włączone wyjście): 1,5 W
Working temperature	-20÷55°C
Dimensions	42×89×31 mm
Assembly	on wall
Ingress Protection Marking	IP65 - hermetic
