Multimeter DMM-1T

DMM-1T, 5908312591801

Product description

Digital. One phase indicator.
DMM-1T multimeter is used for monitoring parameters of one-phase electrical network.

Functioning
* independent current measurement for each phase
* direct measurement 0÷5A
* indirect measurement using current transformers in standard current work with 1÷9000/5A range
* setting indicator to proper current transformer values using three buttons on the indicator's front
* phase voltage and phase to phase voltage measurement
* phase frequency measurement



Typesingle-phase multimeter
Power supply voltage230 V AC
Display4-digit LED (14 mm digit height )
Accuracy of indications1%
Maximum current - direct measurement version5:00 AM
Maximum current - intermediate measurement versiondepends on the transformer used
Possible type of transformer to connect1÷9000/5 A
The range of measured voltage12÷400V AC
Frequency range10÷100 Hz
Terminalpluggable terminal blocks 1,5 mm²
Tightening torque0,4 Nm
Power consumption3 VA
Working temperature-5÷50°C
Dimensions96 mm x 96 mm x 92 mm
Mounting hole92 mm × 92 mm
AssemblyFront of control cabinet
Ingress Protection MarkingIP20

DMM-1T manual (51.47k)

DMM-1T outline CAD dxf (76.94k)

DMM declaration CE 2024 (178.7k)
