Electronic bistable impulse relay BIS-403 230 V

View larger

Display all pictures

Product
Data sheet
Scheme
Tips
Comparision table
Download

Electronic bistable impulse relay BIS-403 230 V

Reference: BIS-403, EAN13: 5908312594086

Product description

Electronic bi-stable pulse relays enables the user to actuate lighting or other devices from various locations by means of control buttons in parallel connection.
Power supply 230 V AC. Maximum load 10 A. To under plaster box Ø60.

Functioning
The receiver is actuated by means of a current pulse triggered by pushing any bell push connected to the relay. The receiver is deactivated by another pulse or after a preset time. Long press, lasting a minimum of 2 seconds, press the button will attach the contact permanently in continuous lighting mode until another pulse has been sent to deactivate the relay.

The relay does not “memorize” the position of the relay contact, i.e. in case of supply voltage decay and the subsequent return of supply voltage, the relay contact will be set in the off position. Such a solution prevents the automatic actuation of the receivers controlled that might occur without proper supervision after a long-lasting decay of supply voltage.

Attention!
The BIS-403 is not compatible with bell pushes equipped with fluorescent lamps.

Power supply voltage	230 V AC
Local control	YES
Maximum AC-1 load current	10 A
The executive element	relay
Contact configuration	1 × NO
Separation of the contact	NO
Resistance to shock currents	NO
Number of channels	1
functionality	ON/OFFwith time switch
Delay of operation	0,1 ÷ 0,2 s
Control pulse current	less than 1 mA
Status memory after power failure	NO
Turn-off time	1÷12 min.
Activate on time	YES
Dedicated central control inputs	NO
Radio control	NO
Terminal	4×DY 1mm²; length: 10 cm
Tightening torque	0,4 Nm
Power consumption	0,8 W
Working temperature	-25 ÷ 50 °C
Dimensions	Ø 55 mm; height: 13 mm
Assembly	in a flush-mounted box Ø60
Ingress Protection Marking	IP20

BIS-403 230 V manual (650.66k)

BIS declaration CE 2024 (180.09k)

BIS-403 Bedienungsanleitung (658.59k)

Maksymalny prąd obciążenia
Prąd styku podany w danych technicznych jest wartością maksymalną i może podlegać ograniczeniom – więcej informacji. Jeśli z przedstawionych informacji wynika, że przekaźnik w urządzeniu jest niewystarczający zaleca się stosować zewnętrzny element przełączający (np. stycznik) przystosowany do przełączania dużych prądów udarowych.

Przyciski podświetlane
Przekażnik bistabilny BIS-403 nie współpracuje z przyciskami podświetlanymi.

Pamięć stanu
Przekaźnik nie posiada "pamięci" pozycji styku, tzn., że w przypadku zaniku napięcia zasilania i jego ponownym powrocie styk przekaźnika zostanie ustawiony w stan wyłączenia. Uniemożliwia to samoczynne załączenie sterowanych odbiorników bez nadzoru po długotrwałym zaniku napięcia zasilania.
