Logic module / 32-channel on / off controller

Logic module / 32-channel on / off controller

mH-IO32

The mH-IO32 input/output module is the basic F&Home system module equipped with 32 binary inputs and 32 binary outputs (operating on the on/off basis).

The module is mounted in the switchgear where it occupies a field of 6 modules and is supplied with 24 V DC voltage. The buttons that are located on the building are directed to the inputs of the module and connected by UTP wires. The module manages the lighting and other receivers via relay actuator modules of the mH-R8x8 or mH-R2x16-type on the on/off basis. The control is carried out fully on a 24 V low voltage line, which ensures full safety and allows for any layout of control buttons in the building. The mH-IO32 module communicates with touch panels via the CAN line. Any module output can be triggered by touch panels by selecting a specific device or scene (device group). From the touch panel, it is possible to program a temporary automatic switching on/off of devices or groups of devices controlled from the input/output module. Additionally, four module inputs are dedicated to control the operation of the mH-LH4 lighting dimmer module via the CAN network.
