Sixteen-channel scene module

Sixteen-channel scene module

mH-MS

The mH-MS scene module is a dedicated component of the F&Home system to control scenes configured on the mH-TS12 or mH-TS15 touch panel using the normally open (bell) buttons.

The module is mounted in the switchgear where it occupies a field of 5 modules and is supplied with 24 V DC voltage. The buttons that are located throughout the building are directed to the inputs of the module and connected by UTP wires. The control is carried out fully on a 24 V low voltage line, which ensures full safety and allows for any layout of control buttons in the building. The mH-MS module communicates with the system via the CAN line.

mH-MS manual (741.48k)
