Staircase timer AS-222T 230 V
230 V power supply. Maximum load 10 A. For 35 mm mounting rail.
With a light-off indication function and an anti-lock function.
The staircase timer is used to keep the lighting in corridors, stairwells or other areas switched on for a specified period of time, after which the lighting will switch off automatically.
Operation
When activated by a momentary (bell-type) switch, the staircase light control unit maintains the lighting for the duration set by the dial; after this time has elapsed, the brightness of the lighting is reduced by half for approximately 30 seconds. Only after this time will the lighting switch off completely (this prevents sudden darkness and allows time to reach the switch safely). Whilst the lighting is at reduced brightness, pressing the switch again will restore the lighting to full brightness.
Anti-lock function
The anti-blocking function prevents the lighting from remaining on continuously if the staircase switch is blocked; that is, if the switch is blocked (e.g. with a match), the unit will count down the set time and switch the lighting off. The lighting can be switched on again once the block has been removed.
NOTE!
The AS-222T is not compatible with fluorescent lamps, compact fluorescent lamps or other lamps with electronic ballasts.
- Power supply voltage
- 230 V AC
- Maximum AC-1 load current
- 10 A
- The executive element
- relay + triac
- Contact configuration
- 1 × NO
- Separation of the contact
- NO
- Delay of operation
- less than 1 s
- Switch off delay - adjustable
- 0,5 ÷ 10 min
- the anti-blockade
- YES
- Switching off indication
- YES
- Cooperation with illuminated buttons
- NO
- Time to maintain the light with reduced brightness
- 30 s
- Terminal
- pluggable terminal blocks 4,0 mm²
- Tightening torque
- 0,5 Nm
- Power consumption
- 0,8 W
- Working temperature
- -25 ÷ 50 °C
- Dimensions
- 2 modules (35 mm)
- Assembly
- on rail 35 mm
- Ingress Protection Marking
- IP20
Prąd styku podany w danych technicznych jest wartością maksymalną i może podlegać ograniczeniom – więcej informacji.
Źródła światła
Ze względu na budowę automatu schodowego nie należy stosować lamp jarzeniowych, świetlówek kompaktowych i innych lamp z elektronicznymi zapłonnikami.
Napięcie zasilania
Automat schodowy AS-222T występuje wyłącznie w wykonaniu zasilanym napięciem 230 V.
Funkcja przeciwblokady
Funkcja przeciwblokady nie pozwala na ciągłe świecenie oświetlenia po zablokowaniu wyłącznika schodowego, tzn. po zablokowaniu wyłącznika (np. zapałką) automat odmierzy zadany czas i wyłączy oświetlenie. Ponowne załączenie oświetlenia może nastąpić po usunięciu blokady.
